Input Voltage: AC 90–260V / 50/60Hz

Light Source: SMD2835

Number of Lamp Beads: 1200 pcs

Light Source Lifespan: 50,000 hours

Luminous Flux: (19.6 lm @ 3200K; 21 lm @ 5600K, standard value)

Luminous Efficacy: (105 lm/W @ 3200K; 110 lm/W @ 5600K, standard value)

Color Temperature: 3200K / 5600K / Dual-color (3200K + 5600K) Selectable

Color Rendering Index: Ra ≥ 95

Dimming: 0–100% Linear Electronic Dimming (16-bit Flicker-free Dimming)

Control Method: DMX512 Console Protocol

Control Mode: 2CH / 4CH

Operation: Nixie Tube Display for Controlling Address Code and Dimming Value

Tilt Angle: 0–90°

Transmission Mode: High-precision Magnetic Encoding & Belt Drive

Operating Temperature: -10℃–40℃

Cooling System: Natural Heat Dissipation via High Thermal Conductivity Pure Aluminum Formed Radiator

Installation Method: Hoisting, Ceiling Mounting, Recessed Mounting

Without Frame: Cut-out Size: 500×380mm; Overall Dimensions: 530×390×90mm

With Frame: Overall Dimensions: 590×460×90mm; Cut-out Size: 550×420mm

Net Weight: 7.9kg

Gross Weight: 9.8kg
