Voltage: AC 100V~240V, 50/60Hz

Power: 500W

Light Source: Osram 350W 17R (7500K)

Bulb Lifespan: Average lifespan of 2000 hours

Lumen: 212,000 @ 10m

Zoom: 0~100% linear smooth zoom

Dimming: 0~100% linear free dimming

Color: 13 colors + white light; half-color effect, bidirectional rotation, rainbow effect, adjustable speed

Gobo: 13 fixed exquisite gobos + white light; gobo shaking effect, bidirectional rotating gobo effect, adjustable speed

Prism: 2 independent rotating prisms (8-facet + 24-facet); knob-adjustable speed, frost effect

Optics: High-precision multi-layer coated light-leakage-proof optical lenses

X/Y Motors: Adopt three-phase stepper motors for faster speed, stronger power and lower noise

Channel Mode: 16 DMX512 channels

Control Mode: International standard DMX 512 / Random Mode / Sound Active Mode / Auto Run Mode

Display Screen: 16-million-pixel LCD touch screen; support normal/inverted display, switchable between Chinese and English

Pan (X-axis): 540° / 2.0s

Tilt (Y-axis): 270° / 1.0s; with automatic correction and positioning function

Beam Angle: Parallel beam angle 0~2.3°; frosted beam angle 8°

Strobe: Dual-strobe structure design; adjustable from 0.5 to 14 times per second; random strobe and pulse strobe selectable

Appearance: High-temperature-resistant plastic shell, high-strength alloy cold-pressed core material

Fixture Dimensions: 360×262×578mm

Package Dimensions: 330×310×580mm (1 unit/package)

Net Weight: 15kg

Gross Weight: 18kg

Installation Accessories: 2 lighting clamps, 1 safety cable Terminology Notes
