Voltage: AC 100-240V, 50/60Hz

Power: 500W

Light Source: Custom High-brightness 380W

Beam Angle: BEAM: 5°

Light Source Lifespan: 2000 hours; 13 colors + white, color flow effect, rainbow color effect achievable; 1 fixed gobo wheel with 13 fixed gobos + white light; independent frost softening effect, RGB prism effect

Mechanical Linear Dimming: 0~100%; fast strobe with multiple strobe modes selectable: pulse (slow/medium/fast), gradient (slow/medium/fast), random (slow/medium/fast)

Prisms: 1 eight-facet prism, 1 twenty-four-facet prism; overlap available, bidirectional rotation supported; Pan: 540°, precision 2.11°/step, fine-tuning precision 0.008°; Tilt: 240°, precision 1.05°/step, fine-tuning precision 0.004°

Control Channels: 18 standard DMX channel control mode

Menu Display: 1.8-inch color screen with buttons, switchable between Chinese and English at will; font can be automatically flipped 180° for display; X/Y-axis three-phase motor drive; RDM bidirectional data transmission

Net Weight: 19kg

Gross Weight: 22kg

Product Dimensions: 376×270×617mm

Package Dimensions: 480×420×590mm

Installation Accessories: 2 lighting clamps, 1 safety cable
