Light Source: Imported High-brightness 380W Bulb

Light Source Lifespan: 2,000 Hours

Beam Exit Aperture: 152mm

Beam Angle: 2°

Control Channels: 16CH

Control Protocols: DMX512, RDM

Control Panel: LCD Screen + Buttons, supporting free switching between Chinese and English, with automatic 180° upside-down display function

Pan Rotation: 540°, Precision: 2.11° per Step, Fine-tuning Precision: 0.008°

Tilt Rotation: 240°, Precision: 1.05° per Step, Fine-tuning Precision: 0.004°

Automatic Calibration for Pan/Tilt Position Out-of-step

Fixed Gobo Wheel: 1 Fixed Gobo Wheel with 13 Fixed Gobos plus White Circle

Color Wheel: 1 Color Wheel with 14 Fixed Colors plus White, supporting color flow and bidirectional rainbow effects

Prisms: Dual Prism Wheels (1×8-facet Prism, 1×48-facet Prism), enabling bidirectional rotation and superposition of the two prisms

Effect Configuration:

Independent Frosting Soft Light Effect, Color Wheel Effect

Mechanical Linear Dimming: 0~100%

Fast Stroboscopic Effect with Multiple Modes: Pulse (Slow/Medium/Fast), Gradient (Slow/Medium/Fast), Random (Slow/Medium/Fast)

Electrical Specifications & Interfaces:

Input Voltage: 100-240V, 50/60Hz

Power: 500W

Power Socket: Power Connector Input/Output

Signal Input/Output: 3-pin XLR Sockets

Fixture Dimensions: 313mm (L) × 248mm (W) × 515mm (H)

Net Weight of Fixture: 13kg

Maximum Ambient Temperature: 40°C

Minimum Operating Temperature: 0°C

Protection Rating: IP20

Installation:Suitable for Horizontal or Vertical Installation，2 Pairs of 1/4-turn Lock Holes at the Bottom

Factory Configuration:User Manual，Power Cable，Signal Cable
