1. Beam Light Source: Imported High-brightness 420W Bulb

2. Secondary Light Source: 33 PCS 0.5W RGB 3-in-1 LEDs

3. Beam Light Source Lifespan: 2,000 Hours

4. Secondary Light Source Lifespan: 20,000 Hours  Optical System

5. Beam Exit Aperture: 165mm

6. Beam Angle: 2° Advanced and High-efficiency Coated Optical System Control & Programming

7. DMX Channel Modes: 2 Modes

8. Control Channels: 24/28CH

9. Control Protocols: DMX512, RDMControl Panel: LCD Screen + Buttons, Support Switching Between Chinese and English Languages at Will, with Automatic 180° Upside-down Display Function X-axis/Y-axis

10. Horizontal Rotation: 540°, Precision: 2.11° per Step, Fine-tuning Precision: 0.008°

11. Vertical Rotation: 240°, Precision: 1.05° per Step, Fine-tuning Precision: 0.004°

Automatic Calibration for X-axis/Y-axis Position Out-of-step Fixed Gobo Wheel 1 Fixed Gobo Wheel with 13 Fixed Gobos plus White Circle Color Wheel 1 Color Wheel with 14 Fixed Colors plus White, Supporting Color Flow and Bidirectional Rainbow Effects

Prisms Dual Prism Wheels (1×8-facet Prism, 1×24-facet Prism), Enabling Bidirectional Rotation and Superposition of the 8-facet and 24-facet Prisms Effect Configuration

Independent Frosting Soft Light Effect, Color Wheel Effect

12. Mechanical Linear Dimming: 0~100%

13. Fast Stroboscopic Effect with Multiple Stroboscopic Modes Optional: Pulse (Slow/Medium/Fast), Gradient (Slow/Medium/Fast), Random (Slow/Medium/Fast)

Electrical Specifications & Interfaces

14. Input Voltage: 100-240V, 50/60Hz

• 15. Power: 600W

• 16. Power Socket: Power Connector Input/Output

• 17. Signal Input/Output: 3-pin XLR Sockets Fixture Specifications

• 18. Fixture Dimensions: 385mm (L) × 270mm (W) × 565mm (H)

• 19. Net Weight of Fixture: 18kg Operating Environment

• 20. Maximum Ambient Temperature: 40°C

• 21. Minimum Operating Temperature: 0°C

• 22. Protection Rating: IP20 Installation Suitable for Horizontal or Vertical Installation

• 2 Pairs of 1/4-turn Lock Holes at the Bottom

23. Factory Configuration：User Manual 、Power Cable、Signal Cable
