Light Source: 700W LED White Light Module

Color Temperature: 9200K

Luminous Flux: 39,000lm

Light Source Lifespan: 20,000 Hours

Light Output Aperture: 145mm

Zoom Angle: 5°-48°

Control Channels: 33CH

Control Protocol: DMX512, RDM

Control Panel: LCD Display + Touch Buttons, supporting free switching between Chinese and English, with 180° automatic screen rotation; Pan/Tilt Range: 540° horizontal, 240° vertical; Step Accuracy: 2.11°/step (horizontal), 1.05°/step (vertical); Fine-tuning Accuracy: 0.008° (horizontal), 0.004° (vertical); Pan/Tilt position automatic correction for out-of-sync

Fixed Locks: Horizontal/Vertical Locks

Linear CTO Color Temperature Adjustment: 2,700K-6,200K; 1 Color Wheel with 7 Fixed Colors + White

Gobo Wheels: 1 Fixed Gobo Wheel with 9 Fixed Gobos + White Circle; 1 Rotating Gobo Wheel with 7 Glass Gobos + White Circle

Gobo Diameter: 22.8mm; Pattern Diameter: 17mm

Gobo Thickness: 1.1mm

Effect Wheel/Dynamic Wheel: 1 Dynamic Effect Wheel, delivering outstanding water ripple effect; the effect wheel is rotatable

Frost Filter: 1 Frost Filter for softening effect

Cutting System: 4 Cutting Blades for fast and smooth beam shaping; each blade can be independently controlled in direction and angle, with single-blade full beam cutoff; the entire cutting module can rotate ±45°

Other Effects: Multiple speed stroboscopic effects

Mechanical Linear Dimming: 0-100% smooth dimming

Input Voltage: 100-240V, 50/60Hz

Power: 850W

Power Socket: Power Connector Input/Output

Signal Input/Output: 3-pin XLR Socket

Luminaire Dimensions: 424mm (L) × 304mm (W) × 764mm (H)

Luminaire Net Weight: 30kg

Maximum Ambient Temperature: 40°C

Minimum Operating Temperature: 0°C

Protection Class: IP20

Installation: Suitable for horizontal or vertical installation, with 2 pairs of 1/4-turn locking holes at the bottom

Factory Configuration: User Manual, Power Cable, Signal Cable
