• 1. Solve the problem that the speaker in the traditional conference room is too large in size and looks unaesthetic when mounted on the wall.

• Through the constant beam technology in the line array column speaker, solve the problem of projection and interference of the speaker in the traditional conference room.

• In terms of sound performance, it is excellent for amplifying human voices in language-based situations.

• The array column speaker adopts a streamlined design, which is beautiful and practical in appearance. It is suitable for sound reinforcement in various building spaces and has a beautiful and pleasant sound quality.

• The circular waveguide holes at the front and the damping ports at the rear of the cabinet form a unique low-frequency cardioid diffusion. The treble is crisp and pleasant, the timbre is natural and rich, and the bass is full.

• It has a built-in frequency divider and protection device.

• The sound pressure level is evenly distributed. It is not harsh to listen to in the near field, and the sound is clear in the far field.

• It has the characteristics of low feedback howling with full plane wave properties.

• The non-compressed horn will not cause the microphone feedback howling.

Unit: 8*4.5 inches woofer, 1*1.5 inches tweeter

Frequency response (Hz): 100Hz - 20kHz

Sensitivity (@1W/1m): 100dB

Power/W (rated/long-term/peak): 300W/600W/1200W

Maximum sound pressure level: 124dB

Peak sound pressure level: 130dB

Impedance: 4Ω

Coverage angle (horizontal*vertical): 110°*130°

Interface: 2*NL4Speakon (1+/1-)

Cabinet material: 15mm plywood

Appearance process: Spraying process

Dimensions (height*width*depth): 1100*146*150mm

Net weight (KG): 10.5Kg

Hoisting accessories: SAP-L45HZ wall-mounted installation bracket
